| Operation |
|
| Optics |
Transmission holography - parallax free |
| Magnification |
1x |
| Eye Relief |
Unlimited |
| Length/Width/Height |
5.1\"x2.1\"x2.8\" (130x53x71 mm) |
| Weight |
11.9 oz (372 grams) |
| Temperature |
-40 to 150 F |
| Waterproof |
Submersible to 33 ft depth |
| Sealing |
Fogproof internal optics |
| Color/Finish |
Non reflective black with hard coat finish |
| Adjustment (per click) |
0.5 MOA (1/2\" at 100 yds) |
| Adjustment Range |
+/- 40 MOA travel |
| Mount |
1\" Picatinny (MIL-STD-1913) rail |
| Return to Zero |
Repeatable to 1 MOA after re-mounting |
| Heads-Up-Display Window |
|
| Optical Surfaces |
Anti-glare coating |
| Window Dimensions |
1.20\" x 0.85\" (30 x 23mm) |
| Front Window Material |
1/8\" solid glass |
| Rear Window Material |
Shatter resistant laminate (3/16\" thick) |
| Field of View (100 yds) |
30 yds (28m) at a 4\" eye relief |
| Standard Reticle |
A65/1 |
| Electrical |
|
| Brightness Adjustment Range |
110,000:1 brightest to lowest
|
| Night Vision Brightness Range |
1000:1 with NV switch engaged |
| Function Button Location |
Left side near the rear of sight |
| Power Source |
2x 3.0V Lithium 123 batteries |
| Battery Life |
1,000 continuous hours (lithium) at nominal setting 12; 600 continuous with AA alkaline |
| Brightness Settings |
30 settings with scrolling feature (10 settings for NV use) |
| Auto Battery Check Indicator |
Flashing reticle upon start-up |
| Auto Shut-down |
At 8 hrs- programmable to 4 hrs |
